Disc Neodymium Magnet N45 D8x5mm

$0.125

  • Ask for a rebate

    • Disc NdFeB magnet Diameter 8 mm, height 5 mm

    N45,nickel-plated, axial

    Price and rebate

    500 pcs. 0.16 USA.*
    from 1000 pcs. 0.15 USA.*
    from 5000 pcs. 0.13 USA.*
    from 10000 pcs. 0.12 USA.*
    from 11000 pcs. according to quot



    + -
    Category: Tags: ,

    Description

    Disc Neodymium Magnet N45 D8x5mm-U-Polemag
    Product Name Disc Neodymium Magnet
    Material NdFeB
    Shape Disc
    Size D8 x 5 mm
    Tolerance +/- 0.1 mm
    Direction of magnetization Axis 5 mm
    Coating Nickel-plated (Ni-Cu-Ni)
    Magnetization N45
    Strength approx. 2 kg (approx. 19.6 N)
    Max. working temperature 80°C
    Weight 1.9 g

    Neodymium magnet

    N45 Neodymium magnet

    D8x5 mm N45 Disc Neodymium magnets, like our other super magnets, are made of a special NdFeB alloy, which allows neodymium block magnets to achieve an extreme adhesive force of up to 200 kg. In our shop, you can find blocks with heights ranging from 1 to 25 mm, which makes them very versatile in their use. The blocks have a protective nickel coating, some even have gold plating, making them look very appealing.
